Cl2S2Ti2
MatHub2d-1404-Cl2S2Ti2
| Property |
Value |
| Space group |
(59, 'Pmmn') |
| Crystal system |
rectangular |
| Magnetic |
Yes |
| Band gap (PBE) (eV) |
0.00 |
| Free energy (eV) |
-30.586 |
| Free energy / atom (eV) |
-5.098 |
Lattice Parameters (basic)
| a, b, c (Å): | 3.432 | 4.832 | 30.000 |
| α, β, γ (°): | 90.000 | 90.000 | 90.000 |
Lattice Parameters (computed)
| a, b, c (Å): | 3.525 | 4.990 | 30.000 |
| α, β, γ (°): | 90.000 | 90.000 | 90.000 |
| Property |
Value |
| Band gap |
0.00 eV |
| E-fermi |
-3.040 eV |
| Vacuum level |
2.538 eV |
| VBM |
-3.040 eV |
| CBM |
-3.040 eV |
| Work function |
5.578 eV |
| Direct gap |
No |
| Property |
Value |
| Band gap |
0.00 eV |
| E-fermi |
-3.040 eV |
| Vacuum level |
2.538 eV |
| VBM |
-3.040 eV |
| CBM |
-3.040 eV |
| Work function |
5.578 eV |
| Cij (N/m) |
xx |
yy |
xy |
| xx |
65.603 |
11.451 |
0.000 |
| yy |
11.451 |
95.627 |
0.000 |
| xy |
0.000 |
0.000 |
21.071 |
| Phonon mode at Γ point (THz) |
| Property |
Value |
| from where |
c2db-382 |
